Product Description
Product Introduction
Eaton93PR 15-80kVA UPSTechnical parameters | |||||||
capacity | Rated capacity/Active power(kVA/kW) | 15/15 | 20/20 | 30/30 | 40/40 | 60/60 | 80/80 |
enter | Rated input voltage(Vac) | 380/400/415 | |||||
Input voltage range(Vac) | 201-478 | ||||||
Rated input frequency(Hz) | 50/60 | ||||||
Input frequency range(Hz) | 42-72 | ||||||
Bypass voltage range(Vac) | +/- 15%default,+/- 20%Optional | ||||||
Input power factor | >0.99 | ||||||
Input currentTHDi (@Linear full load) | <3% | ||||||
Output | Rated output voltage(Vac) | 380/400/415 | |||||
Rated output frequency(Hz) | 50/60 | ||||||
Power factor | 1 | ||||||
Output voltage regulation accuracy | ±1% | ||||||
Voltage dynamic transient | ±5% (0~100%Load changes) | ||||||
Output voltageTHDv (@Linear full load) | <2% | ||||||
Inverter overload capacity | 125%Overload10minute | ||||||
efficiency | Inverter mode | >96% | |||||
ESSmodel | 99% | ||||||
in parallel | Number of parallel machines | most4tower | |||||
Battery configuration | Number of batteries | 32-44Festival | |||||
Charging method | CooperateBMS,ABMOr continue to float | ||||||
Connection method | Supports two units operating in parallel with a shared battery. | ||||||
size | W*D*H (mm) | 330*657*528 | 330*690*986 | ||||
weight | net weight(Kg) | 40 | 40 | 44.5 | 45 | 96.5 | 97.5 |
communication | Communication interface | 2indivualMini-SlotCommunication slot,3User-defined input,1indivualRS232interface | |||||
Communication Attachments | Gigabit Network CardGigabit network card;Industrial Gateway CardIndustrial gateway card;EMPTemperature and humidity sensor;AS/400relay/RS-232Interface card | ||||||
other | temperature | 0-50℃* | |||||
humidity | 5-95%No condensation | ||||||
altitude | <1000mNo reduction | ||||||
noise(1m) | ≤65dB | ||||||
Safety regulations | IEC62040-1 | ||||||
EMCcompatible | IEC62040-2 | ||||||
Performance Standards | IEC62040-3 | ||||||
Certification | TLCTel,CQCEnergy saving, earthquake resistance of telecommunications equipment | ||||||
*40-50Temperatures must be reduced for use. | |||||||
Main Product
Company Profile
Beijing Appleton Technology Development Co., Ltd is a research and development, sales.promotion in one of the high-tech companies, Since its inception, has been committedto providing global customers with high-quality UPS uninterruptible power source, por-table power supply, maintenance-free batteries, lithium batteries and other relatedUPS products and professional solutions, ls an important enterprise in China's energy in-dustry, in the UPS uninterruptible power source has a long time of accumulation and ex-perience, the company is Eaton APC Chind's senior agent, has the industry's top designteam, able to provide a variety of personalized custom needs.
Since 2013, we have obtained the management certifcation of lOS 9001, 1S014001IS045001, and the products have obtained the CEROHS FCC lEC certifcation. With pro-fessional support, effcient sales team and competitive pricing advantages, we haveattracted customers from all over the world. Our partner customers are in more than 50countries including the USA, Canada, UK, France, Germany, Australia, Colombia, Chileand Trukiye. Excellent products and excellent service are the basis of our cooperation.believe we can have very pleasant exchanges and deeper cooperation. l frmly believethat the products we supply can bring you huge profts and a bigger market.
Since 2013, we have obtained the management certifcation of lOS 9001, 1S014001IS045001, and the products have obtained the CEROHS FCC lEC certifcation. With pro-fessional support, effcient sales team and competitive pricing advantages, we haveattracted customers from all over the world. Our partner customers are in more than 50countries including the USA, Canada, UK, France, Germany, Australia, Colombia, Chileand Trukiye. Excellent products and excellent service are the basis of our cooperation.believe we can have very pleasant exchanges and deeper cooperation. l frmly believethat the products we supply can bring you huge profts and a bigger market.
Our Factory
Our Certifcate
Exhibition
Packaging & Shipping
FAQ
1.Which UPS brands does Epton distribute?
We represent international brands such as APC by Schneider Electric, Eaton, Santak, and Vertiv Etc. We also offer customized UPS solutions based on specific customer requirements.
2. In which scenarios is the UPS uninterruptible power supply applicable?
We represent international brands such as APC by Schneider Electric, Eaton, Santak, and KELONG. We also offer customized UPS solutions based on specific customer requirements.
3. How long does it take for the products to be shipped?
Under normal circumstances, in-stock products will be shipped within 1–3 working days after order confirmation and payment. Delivery timelines for customized or out-of-stock items will be communicated separately based on specific situations.
4.What payment methods do you accept?
We accept bank transfer (T/T), Alipay, and credit cards (via secure payment gateway)etc. Available options are subject to the order page.
5.Do you provide technical support?
Yes, we offer free technical consultation and remote support. You can reach us via phone, email, or online customer service.
