Product Description
Product Introduction
Technical Specifications | |||||
Nominal Ratings (kVA/kW) | 100 kVA | 120 kVA | 160 kVA | 200 kVA | 250 kVA |
Input | |||||
Nominal input voltage (V) | 380 / 400 / 415 (three-phase and sharing neutral with the bypass input) | ||||
Input voltage range without battery discharge (V)* | 228 to 478 | ||||
Nominal input frequency (Hz) | 50 / 60 | ||||
Input frequency range (Hz) | 40 to 70 | ||||
Bypass voltage tolerance (%) | Upper limit: +10, +15, or +20, default: +15 | ||||
Lower limit: -10, -20, -30, -40, default: -20 | |||||
Bypass frequency tolerance (%) | ±10 | ||||
Input power factor (kW/kVA) | 0.99 | ||||
Input THDi* | <3% (full load), 4% (half load) | ||||
Battery | |||||
Battery bus voltage (VDC) | 360 to 528 , 2 Wire | ||||
Battery charger max. (A) | 30 | 45 | 45 | 60 | 75 |
Output | |||||
Nominal output voltage (V) | 380 / 400 / 415 (three-phase and sharing neutral with the bypass input) | ||||
Nominal output frequency (Hz) | 50 / 60 | ||||
Nominal active power (kW) | 100 | 120 | 160 | 200 | 250 |
THDv with 100% linear load (%) | 1 | ||||
Inverter overload capacity | <105 % for Continuous; <110% for 60min; <125 % 10 min; <150 % for 1 min; >150 % for 200ms | ||||
Efficiency | |||||
Double conversion mode | Up to 97% | ||||
Dynamic online mode | Up to 98.8% | ||||
Eco mode | Up to 99.2% | ||||
Dimensions and weight | |||||
Dimensions (W x D x H), mm | 600 x 850 x 1600 | 600 x 850 x 2000 | |||
Shipping dimensions (W x D x H), mm | 800 x 1000 x 1800 | 800 x 1000 x 2180 | |||
Weight, kg | 315 | 350 | 350 | 412 | 447 |
Shipping weight, kg | 345 | 380 | 380 | 443 | 478 |
General | |||||
Noise at 1 m dBA | 60 | 62 | |||
Altitude | 1500 m no derating, 1500 to 3000 m derate power by 1 % per each 100 m increase | ||||
Protection level | IP20 (IP21, IP31 optional) | ||||
General and safety requirements for UPS | IEC 62040-1 | ||||
EMC requirements for UPS | IEC 62040-2 | ||||
UPS classification according to IEC EN 62040-3 | VFI-SS-111 | ||||
CPSS applications | EN 50171 | ||||
Rail applications | EN 50121-1; EN 50121-5 | ||||
Main Product
Company Profile
Beijing Appleton Technology Development Co., Ltd is a research and development, sales.promotion in one of the high-tech companies, Since its inception, has been committedto providing global customers with high-quality UPS uninterruptible power source, por-table power supply, maintenance-free batteries, lithium batteries and other relatedUPS products and professional solutions, ls an important enterprise in China's energy in-dustry, in the UPS uninterruptible power source has a long time of accumulation and ex-perience, the company is Eaton APC Chind's senior agent, has the industry's top designteam, able to provide a variety of personalized custom needs.
Since 2013, we have obtained the management certifcation of lOS 9001, 1S014001IS045001, and the products have obtained the CEROHS FCC lEC certifcation. With pro-fessional support, effcient sales team and competitive pricing advantages, we haveattracted customers from all over the world. Our partner customers are in more than 50countries including the USA, Canada, UK, France, Germany, Australia, Colombia, Chileand Trukiye. Excellent products and excellent service are the basis of our cooperation.believe we can have very pleasant exchanges and deeper cooperation. l frmly believethat the products we supply can bring you huge profts and a bigger market.
Since 2013, we have obtained the management certifcation of lOS 9001, 1S014001IS045001, and the products have obtained the CEROHS FCC lEC certifcation. With pro-fessional support, effcient sales team and competitive pricing advantages, we haveattracted customers from all over the world. Our partner customers are in more than 50countries including the USA, Canada, UK, France, Germany, Australia, Colombia, Chileand Trukiye. Excellent products and excellent service are the basis of our cooperation.believe we can have very pleasant exchanges and deeper cooperation. l frmly believethat the products we supply can bring you huge profts and a bigger market.
Our Factory
Our Certifcate
Exhibition
Packaging & Shipping
FAQ
1.Which UPS brands does Epton distribute?
We represent international brands such as APC by Schneider Electric, Eaton, Santak, and Vertiv Etc. We also offer customized UPS solutions based on specific customer requirements.
2. In which scenarios is the UPS uninterruptible power supply applicable?
We represent international brands such as APC by Schneider Electric, Eaton, Santak, and KELONG. We also offer customized UPS solutions based on specific customer requirements.
3. How long does it take for the products to be shipped?
Under normal circumstances, in-stock products will be shipped within 1â3 working days after order confirmation and payment. Delivery timelines for customized or out-of-stock items will be communicated separately based on specific situations.
4.What payment methods do you accept?
We accept bank transfer (T/T), Alipay, and credit cards (via secure payment gateway)etc. Available options are subject to the order page.
5.Do you provide technical support?
Yes, we offer free technical consultation and remote support. You can reach us via phone, email, or online customer service.
