Product Description
Product Introduction
Technical Specifications | ||||
Nominal Ratings (kVA) | 30 | 40 | 60 | |
Rectifier Type | 6P | 6P | 6P | |
Input | ||||
Nominal input voltage | 380/400/415 Vac -wire plus ground | |||
Input voltage range | 323 to 478 Vac | |||
Nominal input frequency | 50/60 Hz | |||
Input frequency range | 45 to 55 Hz/55 to 65 Hz | |||
Output Capacity | ||||
Nominal output voltage | 380/400/415 Vac - 3 Phase with Neutral | |||
Output Power Factor | 0.9 | |||
Frequency | ||||
Voltage stability | ±1% (Steady state); ±5% (Transient state) | |||
Transient recovery time | 20 milliseconds to 1% | |||
Frequency stability | ±0.1% (Synchronized with internal clock); | |||
±6% (max)(Synchronized with bypass) | ||||
Overload capability | 101 to 110%, 60 minutes; 111 to 125%, 10 minutes; | |||
126 to 150%, 1 minute | ||||
Voltage distortion | <1% | |||
with linear load | ||||
Voltage distortion with | <5% | |||
100% Non- linear load | ||||
Permissible load unbalance | 100% | |||
Non linear load capability | 100% | |||
Load handing capability without kVA derating | 0.5 lagging to 0.9 lagging | |||
Phase angle | 100% balanced load±1° | |||
displacement | ||||
accuracy | 100% unbalanced load±1° | |||
Dimensions and weight | ||||
Depth (mm) | 810 | |||
Width (mm) | 715 | |||
Height (mm) | 1250 | |||
General | ||||
General and safety requirements for UPS | IEC 62040-1-1 | |||
EMC requirements for UPS | IEC 62040-2 | |||
UPS Classification according to IEC 62040-3 | VFI-SS-111 | |||
*Conditions apply | ||||
*Specifications are subject to change without any prior notification. | ||||
*Specifications considering 400V nominal voltage. | ||||
Technical Specifications | ||||||||
Nominal Ratings (kVA) | 80 | 120 | 160 | 200 | 300 | 400 | 500 | |
Rectifier Type | 6p | 6P | 6P | 6P | 6P | 6P | 12P | |
Input | ||||||||
Nominal input voltage | 380/400/415 Vac 4-wire plus ground | |||||||
Input voltage range | 323 to 478 Vac | |||||||
Nominal input frequency | 50/60 Hz | |||||||
Input frequency range | 45 to 55 Hz/55 to 65 Hz | |||||||
Input current distortion with linear load | 3 to 10% with optional filter | |||||||
(with filter) | ||||||||
Power factor (with filter) | 0.88 to 0.97 with optional filter | |||||||
Output Capacity | ||||||||
Nominal output voltage | 380/400/415 Vac 4-wire plus ground | |||||||
Output Power Factor | 0.9 | |||||||
Frequency | ||||||||
Voltage stability | ±1% (Steady state); ±5% (Transient state) | |||||||
Transient recovery time | 20 milliseconds (max) | |||||||
Frequency stability | ±0.1% (Synchronized with internal clock); ±6% (max)(Synchronized with bypass) | |||||||
Overload capability | 101 to 110%, 60 minutes; 111 to 125%,10 minutes; 126 to 150%, 1 minute; | |||||||
Voltage distortion with linear load | <1% | |||||||
Voltage distortion with 100% Non- linear load | <5% | |||||||
Permissible load unbalance | 100% | |||||||
Non linear load capability | 100% | |||||||
Load handing capability without kVA derating | 0.5 lagging to 0.9 lagging | |||||||
Phase angle displacement accuracy | 100% balanced load | ±1° | ||||||
100% unbalanced load | ±1° | |||||||
Dimensions | ||||||||
Depth (mm) | 875 | 855 | ||||||
Width (mm) | 900 | 1250 | 1640 | 2280 | 2640 | |||
Height (mm) | 1900 | |||||||
General | ||||||||
General and safety requirements for UPS | IEC 62040-1 | |||||||
EMC requirements for UPS | IEC 62040-2 | |||||||
UPS Classification according to IEC 62040-3 | VFI-SS-11 | |||||||
*Conditions apply | ||||||||
*Specifications are subject to change without any prior notification. | ||||||||
Main Product
Company Profile
Beijing Appleton Technology Development Co., Ltd is a research and development, sales.promotion in one of the high-tech companies, Since its inception, has been committedto providing global customers with high-quality UPS uninterruptible power source, por-table power supply, maintenance-free batteries, lithium batteries and other relatedUPS products and professional solutions, ls an important enterprise in China's energy in-dustry, in the UPS uninterruptible power source has a long time of accumulation and ex-perience, the company is Eaton APC Chind's senior agent, has the industry's top designteam, able to provide a variety of personalized custom needs.
Since 2013, we have obtained the management certifcation of lOS 9001, 1S014001IS045001, and the products have obtained the CEROHS FCC lEC certifcation. With pro-fessional support, effcient sales team and competitive pricing advantages, we haveattracted customers from all over the world. Our partner customers are in more than 50countries including the USA, Canada, UK, France, Germany, Australia, Colombia, Chileand Trukiye. Excellent products and excellent service are the basis of our cooperation.believe we can have very pleasant exchanges and deeper cooperation. l frmly believethat the products we supply can bring you huge profts and a bigger market.
Since 2013, we have obtained the management certifcation of lOS 9001, 1S014001IS045001, and the products have obtained the CEROHS FCC lEC certifcation. With pro-fessional support, effcient sales team and competitive pricing advantages, we haveattracted customers from all over the world. Our partner customers are in more than 50countries including the USA, Canada, UK, France, Germany, Australia, Colombia, Chileand Trukiye. Excellent products and excellent service are the basis of our cooperation.believe we can have very pleasant exchanges and deeper cooperation. l frmly believethat the products we supply can bring you huge profts and a bigger market.
Our Factory
Our Certifcate
Exhibition
Packaging & Shipping
FAQ
1.Which UPS brands does Epton distribute?
We represent international brands such as APC by Schneider Electric, Eaton, Santak, and Vertiv Etc. We also offer customized UPS solutions based on specific customer requirements.
2. In which scenarios is the UPS uninterruptible power supply applicable?
We represent international brands such as APC by Schneider Electric, Eaton, Santak, and KELONG. We also offer customized UPS solutions based on specific customer requirements.
3. How long does it take for the products to be shipped?
Under normal circumstances, in-stock products will be shipped within 1–3 working days after order confirmation and payment. Delivery timelines for customized or out-of-stock items will be communicated separately based on specific situations.
4.What payment methods do you accept?
We accept bank transfer (T/T), Alipay, and credit cards (via secure payment gateway)etc. Available options are subject to the order page.
5.Do you provide technical support?
Yes, we offer free technical consultation and remote support. You can reach us via phone, email, or online customer service.
