Product Description
Product Introduction
Eaton 9PX UPS Technical Specification | |||||||
Technical specifications | 1500VA | 3000VA | |||||
Rating(VA/W) | 1500VA/1500W | 3000VA/3000W | |||||
Format | RT2U(tower/rack 2U) | RT3U(tower/rack 3U) | |||||
Electrical characteristics | |||||||
Technology | On-line double conversion with Power Factor Correction (PFC) system | ||||||
Nominal voltage | 200/208/220/230/240V | ||||||
Input voltage range | 176-276V without derating (up to 100-276V with derating) | ||||||
Input frequency range | 40-70Hz, 50/60Hz autoselection, frequency converter mode | ||||||
Efficiency | up to 92.5% in online mode(up to 97.5% in Hi-efficiency mode) | up to 94% in online mode (up to 98% in Hi-efficiency mode) | |||||
Connections | |||||||
Input | 1 IEC C14(10A) | 1 IEC C20(16A) | |||||
Outputs | 8 IEC C13(10A) sockets | 8 IEC C13(10A) sockets+2 IEC C19(16A) sockets | |||||
Batteries | |||||||
Typical backup times* | 300W | 500W | 800W | 1200W | 1800W | 2500W | |
9PX 1500 | 38 | 23 | 13 | 7 | |||
9PX 1500+1 EBM/+4 EBM | 143/536 | 86/319 | 52/192 | 32/120 | |||
9PX 3000 | 60 | 36 | 22 | 13 | 7 | 4 | |
9PX 3000+1 EBM/+4 EBM | 221/824 | 135/504 | 83/307 | 52/194 | 33/122 | 22/82 | |
Battery management | ABM®& temperature compenseted charging method(user selectable), automatic battery test, deep discharge protection, automatic recognition of external bettery units | ||||||
Communication | |||||||
Communication ports | 1 USB port + 1 serial RS232 port +1 mini-terminal block for remote ON/OFF +1 mini-terminal block for remote power off+ 1 mini-terminal block for output relay | ||||||
Communication slot | 1 slot for Network-MS card, ModBus-MS or Relay-MS cards | ||||||
Operating conditions, standards and approvals | |||||||
Operating temeprature | 0 to 40ºC | ||||||
Typical noise level | 35dB | 40dB | |||||
Safety | IEC/EN 62040-1, UL 1778, CSA22.2 | ||||||
EMC | IEC/EN 62040-2, FCC Class B, CISPR22 Class B | ||||||
Approvals & markings | DNV-GL Type approved / CE / CB report / cULus / EAC / RCM / KC / Energy Star | ||||||
Dimensions H × W × D in mm/Weight | |||||||
UPS | 86.5*440*450/18.9kg | 130*440*485/27.4kg | |||||
EBM | 86.5*440*450/29.8kg | 130*440*485/38.2kg | |||||
Customer service and support | |||||||
Warranty | 3 years on electronics,2 years on batteries | ||||||
*Backup times are approximate and may vary with equipment. configuration, battery age, temperature, etc. | |||||||
Parts numbers* | 9PX 1.5kVA | 9PX 3kVA | |||||
UPS | 9PX1500IRTM | 9PX3000IRTM | |||||
EBM | 9PXEBM48RT2U | 9PXEBM72RT3U | |||||
2m battery connection cable | EBMCBL48 | EBMCBL72 | |||||
Marine Fllter** | 9PXMF3KI | ||||||
*All 9PX UPS and EBM are delivered with rack kit. | |||||||
**Marine UPS requires Marine filter(EMC) for IEC/EN 60945 compliance. | |||||||
