Product Description
Product Introduction
Technical Specifications | 9PX 1kVA | 9PX 1.5kVA | 9PX 2.2kVA | 9PX 3kVA | ||
Rated power(VA/W) | 1000VA/1000W | 1500VA/1500W | 2200VA/2200W | 3000VA/3000W | ||
Model | RT2U (Tower/Rack 2U) | RT2U (Tower/Rack 2U) and RT3U (Tower/Rack 3U) | ||||
Electrical characteristics | ||||||
Technology | In-line double conversion system with power factor correction (PFC). | |||||
Nominal voltage | 200/208/220/230/240V | |||||
Mains input voltage range | 176-276V without derating (up to 100-276V with derating) | |||||
Mains input frequency range | 40-70Hz, 50/60Hz auto selection, inverter mode | |||||
Efficiency | Up to 91.5% in mains mode | Up to 92.5% in mains mode | Up to 93.5% in mains mode | Up to 94% in mains mode | ||
(Up to 97.5% in high efficiency mode) | (Up to 97.5% in high efficiency mode) | (up to 98% in high efficiency mode) | (up to 98% in high efficiency mode) | |||
Connections | ||||||
Input | 1 IEC C14(10A) | 1IEC C20(16A) | ||||
Output | 8 IEC C13(10A) socket | 8 IEC C13 (10A) socket + 2 IEC C19 (16A) socket | ||||
Maintain bypass output via Hotswap | 6 IEC 10A socket | |||||
Switch socket group | 2 socket groups | |||||
Battery | ||||||
Typical backup time(min)** | 300W | 500W | 800W | 1200W | 1800W | 2500W |
9PX 1000 | 28 | 16 | 9 | |||
9PX 1000+1EBM/+4EBM | 134/530 | 79/316 | 47/188 | |||
9PX 1500 | 38 | 23 | 13 | 7 | ||
9PX 1500+1EBM/+4EBM | 143/536 | 86/319 | 52/192 | 32/120 | ||
9PX 2200 | 43 | 25 | 15 | 9 | 5 | |
9PX 2200+1EBM/+4 EBM | 206/818 | 123/491 | 74/297 | 47/189 | 29/118 | |
9PX 3000 | 60 | 36 | 22 | 13 | 7 | 4 |
9PX 3000+1EBM/+4EBM | 221/824 | 135/504 | 83/307 | 52/194 | 33/122 | 22/82 |
Battery management | ABM & Temperature Compensated Charging Method (User Selectable), Automatic Battery Testing, Deep Discharge Protection, Automatic Identification of External Battery Packs. | |||||
Communication | ||||||
Communication port | 1 USB port + 1 serial RS232 port + 1 remote on/off terminal + 1 remote power-off terminal + 1 output dry node terminal | |||||
Communication slots | A slot is used to install a network-MS card, a Modbus-MS card, or a dry-node-MS card | |||||
Main Product
Company Profile
Beijing Appleton Technology Development Co., Ltd is a research and development, sales.promotion in one of the high-tech companies, Since its inception, has been committedto providing global customers with high-quality UPS uninterruptible power source, por-table power supply, maintenance-free batteries, lithium batteries and other relatedUPS products and professional solutions, ls an important enterprise in China's energy in-dustry, in the UPS uninterruptible power source has a long time of accumulation and ex-perience, the company is Eaton APC Chind's senior agent, has the industry's top designteam, able to provide a variety of personalized custom needs.
Since 2013, we have obtained the management certifcation of lOS 9001, 1S014001IS045001, and the products have obtained the CEROHS FCC lEC certifcation. With pro-fessional support, effcient sales team and competitive pricing advantages, we haveattracted customers from all over the world. Our partner customers are in more than 50countries including the USA, Canada, UK, France, Germany, Australia, Colombia, Chileand Trukiye. Excellent products and excellent service are the basis of our cooperation.believe we can have very pleasant exchanges and deeper cooperation. l frmly believethat the products we supply can bring you huge profts and a bigger market.
Since 2013, we have obtained the management certifcation of lOS 9001, 1S014001IS045001, and the products have obtained the CEROHS FCC lEC certifcation. With pro-fessional support, effcient sales team and competitive pricing advantages, we haveattracted customers from all over the world. Our partner customers are in more than 50countries including the USA, Canada, UK, France, Germany, Australia, Colombia, Chileand Trukiye. Excellent products and excellent service are the basis of our cooperation.believe we can have very pleasant exchanges and deeper cooperation. l frmly believethat the products we supply can bring you huge profts and a bigger market.
Our Factory
Our Certifcate
Exhibition
Packaging & Shipping
FAQ
1.Which UPS brands does Epton distribute?
We represent international brands such as APC by Schneider Electric, Eaton, Santak, and Vertiv Etc. We also offer customized UPS solutions based on specific customer requirements.
2. In which scenarios is the UPS uninterruptible power supply applicable?
We represent international brands such as APC by Schneider Electric, Eaton, Santak, and KELONG. We also offer customized UPS solutions based on specific customer requirements.
3. How long does it take for the products to be shipped?
Under normal circumstances, in-stock products will be shipped within 1â3 working days after order confirmation and payment. Delivery timelines for customized or out-of-stock items will be communicated separately based on specific situations.
4.What payment methods do you accept?
We accept bank transfer (T/T), Alipay, and credit cards (via secure payment gateway)etc. Available options are subject to the order page.
5.Do you provide technical support?
Yes, we offer free technical consultation and remote support. You can reach us via phone, email, or online customer service.
