Eaton 93T 15-80kVA UPS technical specifications | |||||||||
Capacity | Rated capacity/active power (kVA/kW) | 15/15 | 20/20 | 30/30 | 40/40 | ||||
Input | Rated input voltage (Vac) | 380/400/415 | |||||||
Input voltage range (Vac) | 201-478 | ||||||||
Rated input frequency (Hz) | 50/60 | ||||||||
Input frequency range (Hz) | 40-72 | ||||||||
Bypass voltage range (Vac) | +/- 15% by default, +/- 20% optional | ||||||||
Input power factor | > 0.99 | ||||||||
Input current THDi (@ rated linear load) | < 3% | ||||||||
Output | Rated output voltage (M) | 380/400/415 | |||||||
Rated output frequency (Hz) | 50/60 | ||||||||
Power factor | 1 | ||||||||
Output voltage regulation (steady state) | ±1% | ||||||||
Output voltage tolerance regulation (dynamic) | ±5% (0-100% load variation) | ||||||||
Output voltage THDv (@ full linear load) | < 2% | ||||||||
Inverter overload capacity | 10 minutes, @125% | ||||||||
Productivity | Double-conversion mode | > 96% | |||||||
ESS mode | 99% | ||||||||
Parallel | Parallel unit | Up to 4 | |||||||
Battery configuration | Battery type | VRLA, NiCad,Lithium-ion | |||||||
Battery blocks quantity (with external VRLA batteries) | 32-50** | ||||||||
Battery blocks quantity (with internal VRLA batteries) | 36 | 32 | 36 | 32 | |||||
Charging method | BMS, ABM, or constant float charge | ||||||||
Connection | Support common battery | ||||||||
Dimensions | W*D*H (mm) standard model | 330*657*528 | |||||||
W*D*H (mm) integrated model (with battery compartment) | 380*740*1328 | 380*740*1575 | |||||||
W*D*H (mm) integrated model (without bat-tery compartment) | 380*740*650 | ||||||||
Weight | (Kg) standard model | 40 | 40 | 44.5 | 45 | ||||
(kg) integrated model (without battery com-partment) | 79 | 81 | |||||||
(kg) integrated model (with battery compart- ment but without batteries) | 147 | 149 | 152 | 159 | |||||
(kg) integrated model (with internal batteries) | 237 | 288 | 332 | 399 | |||||
Communication | Communication interface | 2 mini-slots, 3 building alarms inputs, and 1 RS232&1 USB | |||||||
Communication accessories | Gigabit network card; Industrial gateway card; EMP temperature and humidity sensor; AS/400 relay/RS-232 interface card | ||||||||
Others | Temperature | 0-50°C* | |||||||
Humidity | 5-95%, non-condensing | ||||||||
Altitude | < 1500 m, no derating | ||||||||
Noise (1m) | ≤ 65dB | ||||||||
Safety | IEC62040-1 | ||||||||
EMC compatibility | IEC62040-2 | ||||||||
Performance | IEC62040-3 | ||||||||
Certification | TLC, CQC energy saving, and Seismic test report | ||||||||
*Conditions apply | |||||||||
**Please contact Eaton technical personnel for application guidance | |||||||||
