Product Description
Product Introduction
Eaton 93PR 600kWSingle-counter version upsTechnical Specifications | |
Power module | |
Power (kilowatts) | 62.5kW |
Rack options | |
600kW | Configurable maximum10hot-swappable module |
General characteristics | |
Energy-saving system (ESS)Efficiency under the model | Gundam99% |
Efficiency in dual conversion mode | Gundam97.3% |
Parallel function | Maximum support 8External parallel operation |
Battery cold start | support |
soft start | Mains power start , Battery start support Soft start, matching generator, timePower can be set as needed |
Short-time withstand currentIcc | 100kA |
Fault recording function | support |
Key component life detection function | support |
Online Dummy Load TestingECT | support |
ESSParallel operation function | support |
Combined power supply function | support |
Input characteristics | |
Voltage | 380/400/415V |
Voltage range | 301~478V line voltage 175~276VPhase voltage |
Frequency range | 50/60 Hz |
Power factor | > 0.99 |
Input current distortion | < 3% @ 100%Load capacity |
storage battery | |
Battery type | Lithium-ion batteries, compatible with lead-acid and nickel-chromium batteries |
Charging method | Cooperate BMS, ABMOr continue to float |
Battery voltage | 400-690Vdc |
Battery connection | Support parallel operation 1+1Shared battery |
Output | |
Voltage | 380/400/415V4Wire |
Frequency range | 50/60 Hz |
adjust | ± 1%steady state |
Voltage threshold | < 1% (100%)Linear load ) < 5% (Nonlinear load) |
Overload | 125% 10minute |
Certification | |
Safety | IEC62040-1 |
EMC | IEC62040-2 |
performance | IEC62040-3 |
Certificate | Tel /Energy saving/ CE |
Optional accessories | |
• SNMP Card • Modbus RTU • Industrial relay card • PXGMS Card • External Synchronous Control Box •Lithium battery cabinet •Top air vent kit | |
upssize(mm) | |
high | 2000 |
depth | 1000 |
width | 600 |
UPMsize(mm) | |
high | 133.2 (3U) |
depth | 750 |
width | 439 |
weight(kg) | |
UPS (WithoutUPM) | 360 |
UPM | 39 |
Main Product
Company Profile
Beijing Appleton Technology Development Co., Ltd is a research and development, sales.promotion in one of the high-tech companies, Since its inception, has been committedto providing global customers with high-quality UPS uninterruptible power source, por-table power supply, maintenance-free batteries, lithium batteries and other relatedUPS products and professional solutions, ls an important enterprise in China's energy in-dustry, in the UPS uninterruptible power source has a long time of accumulation and ex-perience, the company is Eaton APC Chind's senior agent, has the industry's top designteam, able to provide a variety of personalized custom needs.
Since 2013, we have obtained the management certifcation of lOS 9001, 1S014001IS045001, and the products have obtained the CEROHS FCC lEC certifcation. With pro-fessional support, effcient sales team and competitive pricing advantages, we haveattracted customers from all over the world. Our partner customers are in more than 50countries including the USA, Canada, UK, France, Germany, Australia, Colombia, Chileand Trukiye. Excellent products and excellent service are the basis of our cooperation.believe we can have very pleasant exchanges and deeper cooperation. l frmly believethat the products we supply can bring you huge profts and a bigger market.
Since 2013, we have obtained the management certifcation of lOS 9001, 1S014001IS045001, and the products have obtained the CEROHS FCC lEC certifcation. With pro-fessional support, effcient sales team and competitive pricing advantages, we haveattracted customers from all over the world. Our partner customers are in more than 50countries including the USA, Canada, UK, France, Germany, Australia, Colombia, Chileand Trukiye. Excellent products and excellent service are the basis of our cooperation.believe we can have very pleasant exchanges and deeper cooperation. l frmly believethat the products we supply can bring you huge profts and a bigger market.
Our Factory
Our Certifcate
Exhibition
Packaging & Shipping
FAQ
1.Which UPS brands does Epton distribute?
We represent international brands such as APC by Schneider Electric, Eaton, Santak, and Vertiv Etc. We also offer customized UPS solutions based on specific customer requirements.
2. In which scenarios is the UPS uninterruptible power supply applicable?
We represent international brands such as APC by Schneider Electric, Eaton, Santak, and KELONG. We also offer customized UPS solutions based on specific customer requirements.
3. How long does it take for the products to be shipped?
Under normal circumstances, in-stock products will be shipped within 1–3 working days after order confirmation and payment. Delivery timelines for customized or out-of-stock items will be communicated separately based on specific situations.
4.What payment methods do you accept?
We accept bank transfer (T/T), Alipay, and credit cards (via secure payment gateway)etc. Available options are subject to the order page.
5.Do you provide technical support?
Yes, we offer free technical consultation and remote support. You can reach us via phone, email, or online customer service.
